Newage Stamford AVR SX460 E000-24602 Onan Voltage Regulator 305-0982

Description NEWAGE AVR SX460 Automatic Voltage Regulator Replacement for Generator Model Number: SX460 Product Name : GENERATOR AVR Replacement: Newage Stamford E000-26000,Onan 305-0982 Weight : 0.40KG Size : 17.5*15*6.5cm Warranty: 1Year Application: Biogas Power Generation Natural Gas Power...

Description
NEWAGE AVR SX460 Automatic Voltage Regulator Replacement for Generator
Model Number:SX460
Product Name: GENERATOR AVR
Replacement: Newage Stamford E000-26000,Onan 305-0982
Weight:0.40KG Size: 17.5*15*6.5cm Warranty:1Year
Application:
Biogas Power Generation
Natural Gas Power
Field Engineering
Electric Power
Factory
Fire-fighting
Details Photos
High-Quality Stamford SX460 AVRTech Details


     Input

Voltage

Jumper selectable 95-132V ac or 190-264V ac

Frequency

50-60 Hz nominal

Phase

1

Output

Voltage

max 90V dc at 207V ac input

Current

continuous 4A dc, intermittent 6A for 10 secs

Resistance

15 ohms minimum

Regulation

+/- 1.0%

Thermal Drift

0.05% per deg. C change in AVR ambient

Typical system response

AVR response

20ms

Filed current to 90%

80 ms

Machine Volts to 97%

300ms

External voltage adjustment

+/-10% with 1 k ohm 1 watt trimmer

Under frequency protection

Set point

95% Hz

Slope

170% down to 30 Hz

Unit power dissipation

12 watts maximum

10 watts maximum

Build up voltage

4 Volts @ AVR terminals

Environmental

Vibration

20-100 Hz,50mm/se

100Hz - 2kHz, 3.3g

Operating temperature

-40 to +70 Deg. C

Relative Humidity 0-70 Deg. C

95%

Storage temperature

-55 to +80 Deg. C
