DSE6020 High-Quality Generator Controller Used For Deep Sea Description
Basic Details
Part Name: Controller
OEM Part Number: DSE6020
Cross Reference: Deep Sea DSE6020
Specification
DC SUPPLY
Continuous Voltage Rating: 8 V to 35 V Continuous
Cranking Dropouts:
Able to survive 0 V for 50 mS, providing supply was at least 10 V before dropout and supply recovers to 5 V.
This is achieved without the need for internal batteries. LEDs and backlight will not be maintained during cranking.
Maximum Operating Current: 100 mA at 12 V, 105 mA at 24 V
Maximum Standby Current: 60 mA at 12 V, 55 mA at 24 V
Maximum Sleep Current: 40 mA at 12 V, 35 mA at 24 V
Generator & Mains (Utility)
Voltage Range:
15 V to 415 V AC (Ph to N)
26 V to 719 V AC (Ph to Ph)
Frequency Range: 3.5 Hz to 75 Hz
Inputs
Digital Inputs A to F
Negative switching
Analogue Inputs A to C
Configurable as:
Negative switching digital input
0 Ω to 480 Ω
Analogue Input D
Configurable as:
Negative switching digital input
0 V to 10 V
4 mA to 20 mA
0 Ω to 480 Ω
Outputs
Output A (Fuel): 10 A short term, 5 A continuous, at supply voltage
Output B (Start): 10 A short term, 5 A continuous, at supply voltage
Auxiliary Output C, D, E & F: 2 A DC at supply voltage
Dimensions
Overall: 216 mm x 158 mm x 43 mm (8.5" x 6.2" x 1.5")
Panel Cut-out: 184 mm x 137 mm (7.2" x 5.3")
Maximum Panel Thickness: 8 mm (0.3")
Part Photos
