Lube Filter PH2867

Premium Lube Filter PH2867 features an integrated anti-drainback valve, delivering full-flow oil purification, superior burst strength, and absolute powertrain wear protection for global automotive, industrial, and construction fleets.
Send Inquiry
Chat Now
Description

China Everlasting Parts Co., Ltd. is one of the most professional manufacturers and suppliers of lube filter ph2867 in China. Welcome to wholesale original and genuine lube filter ph2867 from our factory. Contact us for cheap products and OEM service.



PH2867 Product Introduction

Engineered for reliable full-flow filtration, the Lube Filter PH2867 delivers heavy-duty oil purification and vital component protection for premium passenger vehicles, compact construction machinery, and industrial power systems.

PH2867 Technical Specifications

Manufactured to precision tolerances, this spin-on filtration unit incorporates an anti-drainback valve and an internal bypass valve to secure constant lubrication under high pressure.

Parameter Metric Value
Filter Style Spin-On Lube Filter
Outer Diameter (D1) 71.5 mm
Gasket Outer Diameter (D2) 68.0 mm
Gasket Inner Diameter (D3) 64.0 mm
Thread Size (D7) M20 × 1.5
Total Height (H1) 88.0 mm
Canister Height (H2) 86.0 mm
Gasket Thickness (H3) 10.0 mm
Anti-Drainback Valve 1 Unit
Bypass Valve 1 Unit

PH2867 Comprehensive OE Cross-Reference

This interchangeable oil-treating element serves as a direct, verified replacement for the following original equipment manufacturer and aftermarket part numbers across global inventory systems:

Luberfiner: PH2867
Donaldson: P502007
HiFi Filter: T 8307
Mann Filter: W 610/6
FIL Filter: ZP 3100
Fleetguard: LF3691

PH2867 Detailed Product Description

The premium Lube Filter PH2867 represents a highly specialized spin-on solution designed to safeguard internal combustion engines and hydraulic systems against premature wear. Utilizing an engineered blend of cellulose and synthetic microfibers, this canister removes destructive carbon residues, metal shavings, and combustion soot, preventing abrasive oil circulation. The heavy-gauge steel housing provides superior burst strength, resisting extreme pressure spikes during cold weather startups or continuous peak-load operation.

To ensure uninterrupted powertrain protection, the Lube Filter PH2867 features an integrated high-elasticity anti-drainback valve that traps oil inside the canister when the engine is turned off, eliminating friction-heavy dry starts. Simultaneously, the calibrated internal bypass valve activates under high restriction to ensure steady oil delivery even if the lubricant becomes highly viscous. With a precision M20x1.5 thread design and a robust 71.5mm outer diameter, this oil filter provides an absolute bypass-free seal, helping global fleet operators extend oil service intervals, reduce engine downtime, and minimize maintenance overhead.

PH2867 Exact Vehicle & Equipment Applications

This versatile lubrication element is specifically matched to a diverse fleet of commercial luxury vehicles, material handling units, and industrial air systems:

ACURA: MDX II 3,5 / RSX I 2,0 MT / RSX I 2,0 MT / RSX I 2,0 MT / RSX I 2,0 MT / RSX I 2,0 SPORT
AICHI: SR 12 BJ
AIRMAN: AX 12 / AX 15 / AX 17 / AX 22 / AX 25 / AX 30 / AX 33 / AX 35 / HM 10 S / HM 10 SAG-2 / HM 15 S / HM 20 S / HM 30 S / HM 35 S / PDS 90
ATLAS: AM 16 R / AM 21 R / AM 21 R
ATLAS COPCO: AM 15 R / QEP R12
AUSA: MH 25 / MH 35 / MH 35 R
BAROCLEAN: BM 567 VERSION 16
BARONESS: HMA 1560 / HMC 1560 / HMC 1720
BARRETO: 20 RTK
BOBCAT: 2200 / 2200 S
BOKI: 2051
