Oil Filter PH2863B

An oil filter functions in heavy-duty machinery by trapping soot, metallic wear debris, and combustion byproducts within the lubrication loop. It prevents abrasive particles from scuffing precision-machined crankshaft bearings, camshaft lobes, and cylinder walls under high thermal loads. By maintaining a clean oil film, the filter directly mitigates mechanical friction, helps dissipate heat from the engine core, and prevents oil passage clogging. This ensures stable oil pressure and guards against premature engine failure during extended operational cycles.

Send Inquiry

Chat Now

P550065 Oil Filter Kit

Oil Filter PH48

Description

China Everlasting Parts Co., Ltd. is one of the most professional manufacturers and suppliers of oil filter ph2863b in China. Welcome to wholesale original and genuine oil filter ph2863b from our factory. Contact us for cheap products and OEM service.

PH2863B Heavy-Duty Spin-On Oil Filter PH2863B

This heavy-duty spin-on oil filter provides high-efficiency filtration for industrial and construction equipment, protecting engines from premature wear by capturing harmful particulate contaminants.

Designed for high-vibration off-highway applications, this spin-on element utilizes an enhanced media blend to secure maximum structural integrity and reliable fluid flow under cold-start pressures. Featuring an integrated 1.0 bar bypass valve, it guarantees continuous lubrication to vital internal components even if oil viscosity spikes or the media faces high soot loading.

PH2863B Technical Specifications

Parameter	Specification
Filter Type	Spin-On Oil Filter
Outer Diameter 1 (D1)	104.0 mm
Gasket Diameter 2 (D2)	102.0 mm
Inner Ring Diameter 3 (D3)	96.0 mm
Thread Thread 1 (D7)	M20 × 1.5
Total Height 1 (H1)	128.0 mm
Installation Height 2 (H2)	125.0 mm
Base Thickness 3 (H3)	10.0 mm
Bypass Valve Configuration	1 Integrated Valve

PH2863B Cross-Reference Matrix

Luber-finer

PH2863B

HiFi Filter

T 6730

Mann & Hummel

W 921/80

Donaldson

P550067

Fleetguard

LF3407

PH2863B Equipment Applications

This specialized filtration unit delivers precise fitment for a diverse range of medium excavators, forklifts, crawler carriers, and power generators across major industrial fleets:

Excavators & Earthmovers

Compatible with Caterpillar E110 and E70 series, Hitachi EX40, JCB JS70/JZ70, and Kobelco SK060 III / SK070 / SK70SR tracking units.

Material Handling & Forklifts

Engineered for Komatsu FD23, FD25, and FD30-8 industrial trucks, along with Baoli KBD15+ through KBD30 series.

Industrial Power Equipment

Deployed in Airman SDG12S and SDG35S diesel generators, alongside Morooka MST400 and MST600T tracked dumpers running rugged Isuzu and Mitsubishi diesel powerplants.
