AF1855 Air Filter

AF1855 Air Filter is a highly efficient cylindrical induction barrier interchanging with Donaldson P526505 and Luber-Finer LAF3717, preventing microscopic debris ingestion to ensure stable combustion outputs in heavy machinery.

Send Inquiry

Chat Now

AF4973K LAF8630 Air Filter

AF1606K LAF9538 Air Filter

Description

China Everlasting Parts Co., Ltd. is one of the most professional manufacturers and suppliers of af1855 air filter in China. Welcome to wholesale original and genuine af1855 air filter from our factory. Contact us for cheap products and OEM service.

Radial Seal Architecture

AF1855 Air Filter

AF1855 Air Filter features an advanced heavy-duty radial seal architecture tailored for severe operational dust loads. Boasting an external diameter of 150.0 mm and an extended profile height of 380.0 mm, this structurally reinforced canister utilizes deep-pleat media distribution to maximize particulate containment while maintaining low restrictive intake values. The rugged outer wire netting guards against high-vibration structural collapse under intense suction pressure. This critical engine component delivers long-term technical protection across major agricultural and industrial equipment segments, offering drop-in installation for an expansive range of FORD AGRI legacy tractors (including 2310, 2600, 3600, 4600, 4610, 5030, and 6600 systems). Additionally, it ensures clean air delivery metrics for FARMTRAC 535, 550, 675 FT, and 80 FT power setups, as well as CECCATO and COMPAIR-HOLMAN RA 40 and RA 60 mechanical air installations.

AF1855 Cross Reference

FLEETGUARD: AF1855

LUBER-FINER: LAF3717

DONALDSON: P526505

AF1855 Technical Specifications

Component Profile	Absolute Dimensions
Filter Style	Cylindrical Radial Sealing Intake
Outer Diameter 1 (D1)	150.0 mm
Outer Diameter 2 (D2)	130.0 mm
Inner Diameter 3 (D3)	78.0 mm
Total Height 1 (H1)	380.0 mm
Outer Body Height 2 (H2)	375.0 mm
Inner Core Height 3 (H3)	371.0 mm

AF1855 Vehicle

AF1855 Equipment Brand

AF1855 Compatible Machinery Models

CECCATO

RA 40, RA 60

COMPAIR-HOLMAN

RA 40

FARMTRAC

535, 550, 550 DT, 670 FT, 675 FT, 675 FT DT, 685 FT DT, 70 FT, 80 FT

FORD AGRI

2310, 2600, 2610, 3230, 3430, 3600, 3610, 3930, 4100, 4110, 4130, 4600, 4610, 4630, 4830, 5030, 5100, 5110, 5610, 5710, 6600

AF1855 Product Frequently Asked Questions (FAQ)

Q1: Can the AF1855 Air Filter replace the Donaldson P526505 directly without modifications?

A1: Yes, this element is a 100% direct dimensional interchange. It meets identical radial parameters (D1=150.0 mm, H1=380.0 mm) to fit standard factory housings with zero modifications.

Q2: Which specific tractor models are primarily served by this filter?

A2: It provides extensive application coverage for older agricultural fleets, specifically maximizing performance across Ford Agri 2600 through 6600 series and Farmtrac 535/675 models.

Q3: How often should this element be checked or replaced in high-dust agricultural zones?

A3: It should be inspected every 50 to 100 operating hours in dusty field work. Full replacement is recommended at 250 hours or whenever the cabin restriction indicator lights up.

Q4: What happens if raw bypass air passes the inner D3 seal area?

A4: Any seal failure around the 78.0 mm inner diameter allows raw dust to bypass the filtration media, which can cause severe abrasive cylinder wall scoring and accelerated engine wear.

Q5: Is this a washable filter element that can be reused?

A5: No, this uses high-efficiency cellulose pleats. Attempting to wash or spray it with fluids will ruin the paper matrix pore structure, completely degrading its micron rating and dust-holding capacity.
